Mexen G05 angled thermostatic set, Duplex, DN50, chrome - W907-958-01

The Mexen G05 angled thermostatic set offers excellence with its brass construction and chrome finish. Ideal for installation with a connection diameter of G 1/2" and 50 mm spacing. The maximum working temperature is 120°C, and the working pressure is 10 bar. It includes a head with 0-5 regulation and a temperature range of 0-29°C. Features frost protection and can be connected from the left or right side. Includes connectors for multilayer and copper pipes.

Technical data:

Valve material: Brass

Valve colour: Chrome

Valve connection diameter: G 1/2"

Working temperature: max 120 °C

Maximum working pressure: 10 bar

Radiator supply and shut-off valve

Bottom connection with 50 mm spacing

Head thread: M30 x 1.5 mm

Head colour: Chrome

Adjustment scale: 0-5

Temperature adjustment range: 0-29 °C

Ambient temperature: max 50 °C

Frost protection 5°C

Possibility to connect the head from the left or right side of the valve

Includes additional connectors for 16x2 mm multilayer pipes and 15 mm copper pipes

Innovative solutions used in this product

Brass

Making valves from brass ensures their durability, resistance to corrosion, and strength, which is particularly important in environments where there is constant contact with water under pressure and varying temperatures.

Frost Protection

The product features a built-in frost protection function when the temperature drops below 5°C. This function provides protection for the heating system and pipes against freezing, especially during periods of low temperatures when the building is not in use.

Temperature Regulation

The head with a 5-stage temperature regulation scale, ranging from 0-29 °C, allows for precise temperature control. This function enables the user to set the room temperature, which translates to thermal comfort and energy savings.

1 Mpa

The product is designed for use in installations where the working pressure can be up to 1 Mpa (10 bars). This is an important parameter that ensures proper and safe operation in systems with relatively high pressure.

2 years warranty

This product is covered by a 2-year warranty. If you encounter any problems with the purchased product, we encourage you to contact us via the contact form or by phone on the helpline.

Serial
G05
Type
Angular
Colour
Chrome
Connection diameter
G 1/2"
Cover
No
